Features 1、Fast Current Leakage Inspection, Short Circuit ldentification, Complex Bugs Rule Out: Quickly locate high-temperature areas, abnormally high-temperature components color palette and adjustment stability range, short circuit positioning. 2、Intuitive 3D Imaging: Supports viewing circuit boards in 3D mode, which is more intuitive for small current changes. The three-dimensional thermal field distribution intuitively displays temperature changes, suitable for industry, electronics and other industries. 3、Double-board Comparison Mode: Supports comparison of good and bad boards, places items that need to be observed and compared on both sides of the dividing line, and performs comparison and analysis under the same conditions to quickly locate faulty circuit boards. 4、Rectangular Analysis Mode: Supports detailed comparison and detailed inspection of image color changes in different areas, and can display the temperature curve within the frame to facilitate viewing of temperature history data. 5、Adjustable Stand: High-quality metal stand with high-temperature resistant workbench, easy to install, flexibly adjustable and rotating, and the measuring distance can be fine-tuned. Specification The PCBA thermal imaging analysis system is a product that uses infrared thermal imaging technology in the field of circuit board maintenance. This product can assist engineers to quickly locate detect in the circuit board, such as short circuits, current leakage, etc., to improve R&D and troubleshooting efficiency. Features: Fast Current Leakage Inspection, Short Circuit ldentification, Complex Bugs Rule Out: Quickly locate high-temperature areas, abnormally high-temperature components color palette and adjustment stability range, short circuit positioning. Intuitive 3D Imaging: Supports viewing circuit boards in 3D mode, which is more intuitive for small current changes. The three-dimensional thermal field distribution intuitively displays temperature changes, suitable for industry, electronics and other industries. Double-board Comparison Mode: Supports comparison of good and bad boards, places items that need to be observed and compared on both sides of the dividing line, and performs comparison and analysis under the same conditions to quickly locate faulty circuit boards. Rectangular Analysis Mode: Supports detailed comparison and detailed inspection of image color changes in different areas, and can display the temperature curve within the frame to facilitate viewing of temperature history data. Adjustable Stand: High-quality metal stand with high-temperature resistant workbench, easy to install, flexibly adjustable and rotating, and the measuring distance can be fine-tuned. Specifications: Material: Aluminum alloy Resolution: 256 x 192 pixels Frame Rate: 25Hz Temperature Measurement Range: -15℃~600℃ / 5℉~1112℉ Lens Focus of View: 56° x 42° Temperature Measurement Distance: 100mm-150mm (can be observed at 30mm using a macro lens) Device Interface: USB Type-C Image Storage Format: JPG Video Storage Format: MP4 Input Voltage: DC 5V Storage Temperature Range: -20℃~60℃ Working Temperature: 0℃~50℃ Humidity: 95% relative humidity Item Size: 150 * 150 * 230mm / 5.91 * 5.91 * 9.05in Item Weight: 589g / 1.29lb Package Weight: 923g / 2.03lb Package Size: 20.4 * 20.4 * 7.2cm / 8.03 * 8.03 * 2.83in Package List: 1 * Thermal Analyzer 1 * USB A to USB C Data Cable 1 * USB C to C Data Cable 1 * Flash Driver 1 * Macro Lens 1 * User Manual (English) Package List Package List: 1 * Thermal Analyzer 1 * USB A to USB C Data Cable 1 * USB C to C Data Cable 1 * Flash Driver 1 * Macro Lens 1 * User Manual (English)
