Enhance your motor control projects with this high-quality Self-Locking (Bistable) Reverse Polarity Relay Controller Module. Designed for precise forward and reverse polarity switching, this module features a convenient low pulse control mode, making it easy to toggle motor direction with a simple trigger signal. Built with premium electronic components, it guarantees stable and reliable performance for various DC motor applications. Key Features: · **Self-Locking Bistable Design:** Allows the output polarity to switch and hold between forward and reverse with each trigger pulse, eliminating the need for continuous control signals. · **Reverse Polarity Control:** Efficiently controls forward and reverse motor rotation by switching output polarity, ideal for applications requiring directional motor control. · **Low Pulse Control Mode:** Operates with a 0.2-2 second low pulse trigger, simplifying integration and reducing power consumption during switching. · **Dual Indicator Lights:** Equipped with a power indicator and reverse polarity indicator for clear operational status and easy troubleshooting. · **Wide Voltage Compatibility:** Available in two versions supporting DC 5V or DC 6-24V input voltage, providing flexibility for different power supply requirements. · **Compact and Lightweight:** Measures approximately 43 x 21 x 16 mm and weighs only 13.5 g, making it easy to install in tight spaces or portable devices. · **Stable and Reliable Performance:** Made from high-quality electronic components to ensure long-lasting durability and consistent operation under load. · **Safe Load Handling:** Supports a maximum load current of 2A (recommended motor current ≤1A) with load voltage equal to output voltage, suitable for small DC motors. Specifications: · Item Type: CW/CCW Controller Module · Input Voltage: DC 5V (5V version) or DC 6-24V (12V version) · Module Working Current: Forward 2mA, Reverse 35-40mA · Load Voltage: Equal to output voltage · Load Current: Maximum 2A (motor current ≤1A) · Control Mode: Low pulse control (0.2-2 seconds low pulse trigger) · Size: Approx. 43 x 21 x 16 mm (1.7 x 0.8 x 0.6 in) · Weight: Approx. 13.5 g (0.5 oz) Pin Description: · I +: Power input positive · I -: Power input negative · O +: Power output positive (reverses polarity to negative when triggered) · O -: Power output negative (reverses polarity to positive when triggered) · G: Trigger signal ground · T: Trigger signal input Package Includes: · 1 x Self-Locking Reverse Polarity Relay Controller Module This bistable reverse polarity controller module is an ideal solution for motor direction control, robotics, and automation projects. Its self-locking function, clear status indicators, and compact design provide a user-friendly and efficient way to manage forward and reverse motor operations safely and reliably.
